(ø 100-500 mm.)
Nordfab Quick-fit duct system
is manufactured from fully galvanized sheets and is characterized by great stability of form and a smooth surface. The components have a rolled collar,over which the Nordfab Q-F clip is fitted. The clip has an inner gasket to ensure that an air tight seal is achieved. It requires no tools to assemble ormodify.
The Nordfab Quick-Fit system has a complete accessory range wigh 60° Y-pieces, 30° branches, 30° cut in branch, 90° adapters, reducers, sliding
dampers, automatic dampers etc. It ensures individual fitting and great flexibility-including adaptation to other duct systems.
| ØA | Parts No. | ENDS | ØB | THICKNESS | WEIGHT (Kg) |
| 100 | QI100 xxx | QF | 100 | 0.7 | 0.90 |
| 125 | QI125 xxx | QF | ≤125 | 0.7 | 1.28 |
| 140 | QI140 xxx | QF | ≤140 | 0.7 | 1.53 |
| 160 | QI160 xxx | QF | ≤160 | 0.7 | 1.91 |
| 180 | QI180 xxx | QF | ≤180 | 0.7 | 2.33 |
| 200 | QI200 xxx | QF | ≤200 | 0.7 | 2.79 |
| 250 | QI250 xxx | QF | ≤250 | 0.7 | 4.11 |
| 315 | QI315 xxx | QF | ≤315 | 0.7 | 6.20 |
| 350 | QI350 xxx | QF | ≤350 | 0.7 | 7.50 |
| 400 | QI400 xxx | QF | ≤400 | 0.7 | 9.57 |
| 450 | QI450 xxx | QF | ≤450 | 0.7 | 11.89 |
| 500 | QI500 xxx | QF | ≤500 | 0.7 | 14.45 |
